Ford Transit

Ford Transit

Year of production 1965 - ...


Category: Trucks

The Ford Transit is a range of panel vans, minibuses, and pickup trucks, produced by the Ford Motor Company in Europe.

The Transit has been the best-selling light commercial vehicle in Europe for 40 years, and in some countries the term "Transit" has passed into common usage as a generic term applying to any light commercial van in the Transit's size bracket.

Although the Transit name has been in use by Ford since 1953, the first definitive Transit platform was launched in 1965. Since then, six million Transits have been produced across three basic platforms (first debuting in 1965, 1986 and 2001, respectively), with several "facelift" versions of each. The six millionth van was built in March 2010.

The first Ford Transit (1953–1965)

Known in Germany as the "first generation" Transit

Unlike the British-built Transit "family", the first production Ford to wear the "Transit" badge was a van built in Ford's Köln (Cologne) plant in Germany. It was introduced in 1953 as FK 1000 (Ford Köln carrying 1,000 kg). From 1961, this vehicle was called the Ford Taunus Transit. Production of this model ceased in 1965.

Naming system

The German vehicle was not widely exported, and the "Mark 1" tag has commonly been applied, retroactively, to the 1965 to 1978 British model (see below). Whilst there have been three basic Transit platforms since 1965, the various facelifts and upgrades over the years have been referred to using a conflicting range of "Mark" numbers, with some sources counting a facelift as a new "Mark", some not. Ford's own historical look back at Transit production, published for the launch of the 1994 model, avoids the issue by referring to generations of Transit by years produced. This article attempts to make mention of all the common naming systems.

Ford Transit 1965–1978

UK "Mark 1"; Germany "Second generation"

The first Ford Transit proper was introduced in October 1965, and has been in continuous production in three basic generations to the present day. The van was produced initially at Ford's Langley facility in Berkshire, England (a former Second World War aircraft factory which had produced Hawker Hurricane fighters), but demand outstripped the capability of the plant, and production was moved to Southampton, where it has remained. Transits have also been produced in Ford's Genk factory in Belgium and also Turkey. Transits have been produced in Amsterdam for the local market from the mid seventies until the end of 1981. This factory had ample capacity, since the Ford Transcontinentalproduced there had little success (total production 8000 in 6 years). Although the Transit sold well in the Netherlands, it was not enough to save the factory, which closed in December 1981. The Transit is also produced in China for the Chinese market.

The Transit was introduced to replace the Ford Thames 400E, a small mid-engined forward control van noted for its narrow track which was in competition with similar-looking but larger vehicles from the BMC J4 and J2 vans and Rootes Group's Commer PB ranges. In a UK market segment then dominated by the Bedford CA, Ford's Thames competitor, because of its restricted load area, failed to attract fleet users in sufficient numbers. Ford switched to a front engined configuration, as did the 1950s by Bedford with their well-regarded CA series vans. Henry Ford II's revolutionary step was to combine the engineering efforts of Ford of Britain and Ford of Germany to create a prototype for the Ford of Europe of today—previously the two subsidiaries had avoided competing in one another's domestic markets but had been direct competitors in other European markets.

The Transit was a departure from the European commercial vehicles of the day with its American-inspired styling—its broad track gave it a huge advantage in carrying capacity over comparable vehicles of the day. Most of the Transit's mechanical components were adapted from Ford's car range of the time. Another key to the Transit's success was the sheer number of different body styles: panel vans in long and short wheelbase forms, pick-up truck, minibuses, crew-cabs to name but a few.

The engines used in the UK were the Essex V4 for the petrol engined version in 1.7 L and 2.0 L capacities. By using relatively short V-4 engines Ford were able to minimise the additional length necessitated to place the engine ahead of the driver. Another popular development under the bonnet was the equipping of the van with an alternator at time when the UK market competitors expected buyers to be content with adynamo. A 43 bhp (32 kW) diesel engine sourced from Perkins was also offered. As this engine was too long to fit under the Transit's stubby nose, the diesel version featured a longer bonnet. The underpowered Perkins proved unpopular, and was replaced by Ford's own "York" unit in 1974. For mainland Europe the Transit had the German Ford Taunus V4 engine in Cologne 1.7 or Essex 2.0 litre versions. The diesel version's long nose front was also used to accommodate the Ford 3.0 litre V6 in vans supplied to police and ambulance services. In Australia, the long-nose diesel front was used to accommodate an inline 6-cylinder engine derived from the Ford Falcon.

According to the show Top Gear, British police have reported that in the 1970s 95% of all robberies in which the criminals used a vehicle, involved this type of Ford Transit.

The adoption of live axles front and rear in place of a system incorporating independent front suspension that had featured on its UK predecessor might have been seen as a backward step by some, but on the road commentators felt that the Transit's wider track and longer wheelbase more than compensated for the apparent step backwards represented by Ford's suspension choices. Drivers appreciated the elimination of the excessive noise, smell and cabin heat that resulted from placing the driver above or adjacent to the engine compartment in the Thames 400E and other forward control light vans of the 1950s and early 1960s.

Ford Transit 1978–1986

UK "Mark 2"; Germany "Third generation"

In March 1978, a facelifted version—commonly known in some markets as the "Mark 2" model—debuted with a restyled nose section, new interior, and the introduction of the Pinto engine from the Cortina in place of the Essex V4. Many fleet owners experienced premature camshaft wear in early Pinto units in the Cortina and for two years the Transit 75 was available with the 1.6 L Ford Kent "Xflo" engine. High performance versions intended for police or ambulance use used the 3.0 L V6 version of the Essex engine, Australian variants had 4.1 L (250 cu in) inline 6 cylinder engines
In 1984, the York diesel engine was redesigned into the 2.5 L "DI" (direct injection) unit. At this time this generation received a minor facelift including a grey plastic front grille with integrated headlamp surrounds, wrap around indicators, longer bumper end caps and multifunction rear lights incorporating fog, indicator, reversing and side lights for the panel van. This facelift did not commonly result in a new "Mark" number.

The Mark II was available in 6 body styles: Van, Kombi, Chassis Cab, Parcel Van, Bus and Crewbus all available in short (2690mm) and long (3000mm) wheelbase versions. A selection of 5 engines were available: 1.6ltr OHC Petrol, 1.6ltr OHV Petrol (Kent), 2.0ltr OHC Petrol, 2.0ltr OHC Petrol (Economy) and 2.4ltr Diesel. On top of this were 32 door combinations, 6 axle ratios and options for 12 - 17 interior seats. All of these available in any combination when purchased with Ford's highly customizable custom plan. At the time this gave the business sector an unprecedented amount of flexibility which was a major factor in the vehicles ultimate success.

Ford Transit 1986–1991 & minor facelift 1991–1994 (VE6 & VE64 after facelift)

UK "Mark 3" and "Mark 4" after facelift; Germany "Fourth generation"

The second generation Transit platform appeared in January 1986 and was notable for its all-new bodyshell which was of "one-box" design (i.e.the windscreen and bonnet are at the same angle), and the front suspension was changed to a fully independent configuration on SWB versions. The engine range was carried over largely unchanged from the last of the 1978-85 generation models, although in 1989 the high performance 3.0 V6 petrol was replaced by the Cologne 2.9 EFI V6. A subtle facelift in 1992 saw the fully independent front suspension adopted across the range, whilst a redesigned floor plan allowed the use of single, rather than paired, rear wheels on the LWB derivative, further increasing payload—these models are identifiable by the slightly more rounded front headlamps.

This generation of Transit was used by Jeremy Clarkson in Top Gear's Man With Van Challenge, finishing second (vs a tiny Suzuki Super Carry and huge LDV Convoy). This involved buying a van for under £1000, and several tests representing (stereo)typical van use: a quarter-mile drag race (cross-city speed); loading, carrying, and disgorging a load of furniture (space, access); tailgating (visibility, control); replacing a "damaged" door (maintenance); a police chase (handling), etc. The Transit upheld its reputation for agility by performing particularly well in the final chase, "resisting arrest" much longer than the slow LDV and unstable Suzuki, which overturned at the first curve.

Ford Transit 1994–2003 (VE83)

UK "Mark 5"; Germany "Fifth generation"

A major facelift to the Transit in 1994/5 gave the Transit a new nose and dashboard, along with the 2.0 L DOHC 8-valve engine as found in the 1994 to 1998 Ford Scorpio. It is similar to the earlier Sierra DOHC unit but without the distributor and uses the updated OBD II-compliant EEC-V level engine control unit. Some of Ford's 16-valve engines, such as those found in the Scorpio, Escort RS2000 and Galaxy were also based on this block. At the same time air conditioning, electric windows, central locking, electric mirrors and airbags were all made available as optional extras.

The turbo diesel version came in 85 PS (63 kW), 100 PS (74 kW) and 115 PS (85 kW) version with an electronic fuel pump.

For the 30th anniversary of the Transit in 1995 Ford released a limited edition model called the Transit Hallmark. Six hundred were made and were available in three colours with 200 being made in each.

In Europe the VE83 Transit was available up to 2000, but in Vietnam it was built up to 2003 when it was exchanged in June for the new generation.

Ford Transit 2000–2006 (V184/5)

UK "Mark 7"; Germany "Seventh generation"

The next Transit, introduced in July 2000, was the third all-new design, and borrowed styling cues from Ford's "New Edge" designs like theFocus, and Ka. Developed by Ford in the United States, the main innovation is that it is available in either front or rear-wheel drive. Ford nomenclature makes this the V184 (rear wheel drive) or V185 (front wheel drive) model. This model features the "Puma"-type Duratorq turbo diesel engine also used in the 2000 Mondeo and Jaguar X-Type, with the petrol versions moving up to the 2.3 L 16-Valve edition of the straight-4 engine. With this engine, the Transit can reach 60 mph (97 km/h) in 21 seconds and reach a top speed of 93 miles per hour (150 km/h), returning it to car-like performance as claimed for the earliest models. A demonstration of this model's speed was shown on Top Gear in 2005, where German race driver Sabine Schmitz attempted to drive it around the Nürburgring in under ten minutes, matching Jeremy Clarkson's time in a turbodiesel Jaguar S-type; she was unsuccessful, but only by a few seconds.

This version won the International Van of the Year 2001.

The Durashift EST automatic transmission (optional on all rear-wheel drive models) features controls mounted on the dashboard, a specially adapted manual mode, tow-haul mode, economy mode and winter mode.

Two years later, Ford introduced the Transit Connect, a smaller panel van based on the C170 (Focus) platform and aimed at replacing the olderEscort and Fiesta based models. It shares very little with the full-size Transit in terms of engineering, although is produced alongside the larger van in a new purpose built facility in Turkey.

2002 saw the introduction of the first High Pressure Common Rail diesel engine in the Transit, with the launch of the 125 PS (92 kW) HPCR 2.0 litre in the FWD.

2003 saw a new instrument cluster with a digital odometer.

2004 saw the launch of the first RWD HPCR, the 135 PS (99 kW) 2.4 litre variant that also introduced the 6-speed MT-82 RWD gearbox.

The five millionth Transit rolled off the Southampton line on Monday, 18 July 2005 and was donated to an English charity.

Ford Transit 2006–present (China: VJX6541DK-M)

The Ford Transit VJX6541DK-M is the Chinese version and it based on its predecessors of the fourth and fifth generation. This generation is only built in Nanchang by Jiangling Motors and is reserved for the Chinese domestic market. Remarkable are the much larger headlights and the larger grille. The model was launched to the market in 2006. Overall, the generation have 70 improvements to its predecessor. The interior has been changed and made more ergonomic. Power windows are standard, but ABS is optional. The Chinese Transit is available with two diesel engines and one petrol. One of them has a power of 67.6 kW (Type JX493ZQ3), the other 68 kW (JX493ZQ4). Both diesels have a capacity of 2771 cc. The Petrol version uses a Ford Barra engine 190 kW inline-6 motor. The top speed is specified at 68.35 mph (110 km/h). The Chinese Transits have a VIN in following form: LJXBMCH1××T××××××.

The European 2006 Ford Transit went into production in 2008. On the Chinese market it is known as the New Transit. It is offered parallel to the 2006 China generation. The two facilities are currently manufacturing 300,000 units annually. Ford and Jiangling want to open a third plant in late 2012 to increase the annual production to further 3,000 units.

In January 2010, the Toyota recalls affected the products of the Ford Group because Ford used the same supplier (CTS Corporation). It was suspected that the accelerator pedals were defective and posed a danger. About 1600 Ford Transits of the 2006 China generation were affected by the recall.

The European models of the VE6 and VE8 generation can be given an aftermarket facelift to the Chinese version. This needs the Chinese components and manual skills.

Ford Transit 2006–present (Europe: V347/8; China: unknown)

UK "Mark 7"; Germany "Seventh generation"

In August 2006, the Transit received a facelift to the body, including new front and rear lights, a new front end and a new interior featuring the gearstick on the dashboard and Ford's new corporate radio design. Besides the styling changes, the powertrains were revised. The old petrol engine was replaced with one from the Ford Ranger, the front wheel drive diesel went from 2.0 to 2.2 litres capacity, and all diesel engines gained high-pressure common rail (TDCi) systems. The powertrains were changed to meet new emissions legislation. The new version (Ford nomenclature V347 for front wheel drive and V348 for rear wheel drive) won International Van of the Year for 2007 despite tough competition from several all-new rivals.

Mid 2006 saw the launch of the "Sport Van", a limited production Van featuring the 130 PS (96 kW) engine with additional styling parts, "Le Mans" stripes and 18 inch alloy wheels.

Late 2007 saw the launch of the 140 PS (103 kW) engine for front wheel drives (replacing the 130 PS) complete with the VMT6 6-speed transaxle to cope with the extra power.

The 6-speed transaxle was introduced on the mid-power FWD in late 2008 when the 110 PS (81 kW) engine was upped to 115 PS (85 kW).

In late 2008, the "coated Diesel Particulate Filter" (cDPF)—designed to meet higher emission standards than the current Euro IV requirement—was introduced as an option on all diesel engines.

Ford Transit County 4x4

A handful of companies offered four-wheel-drive conversions, such as County Tractors of Knighton in Powys, who converted vans on behalf of Ford as a Special Vehicle Operations (SVO) factory option. The first Transit County models were based on the Mk2 Transit model, both long and short wheelbase. The conversion used a Dana 44F front axle and a NP208 transfer box, both lifted from the Ford Bronco, coupled to the regular Transit engine, gearbox and rear axle using three custom propshafts. The Transit rear axle was retained, mounted to a rear subframe or 'lift cradle' to give the extra ride height. Other modifications were 16 inch wheel rims, locking front hubs, a heavy-duty steering box and 305mm diameter front brake discs.

With the introduction of the Mk3 Transit in 1986 came the next generation of the County 4x4. This would prove to be a very popular and successful version of the County Transit 4x4, and the last to use the Dana beam axle layout. Later County 4x4 models switched to using an independent front suspension setup which was inherently more complex in design than the earlier beam axle models. Later panel vans also lost the twin-wheel rear axle that had been fitted on earlier LWB versions.

Mainly used by utility companies such as National Grid, the Ministry Of Defence, and by mountain rescue teams, the Transit County 4x4 proved to be a capable vehicle both on and off road, with the ability to carry both crew and equipment just about anywhere.

Design and supply of drivetrain components for County 4x4 models passed to Countytrac, a division of M.J. Allen Ltd, who are still involved in the development of the latest Mk7 AWD Transit and Connect models.

Ford Transit XXL

To celebrate the Transit's status as International Van of the Year 2007, Ford built this stretch limo style van—the Transit XXL. It is a unique special that is among the most expensive Transits ever.

Ford Transit 2013 "prototype" (North America: T-Series)

Mark 8; MK8; Eighth Generation
In September of 2011 a prototype Transit was spotted in the Austrian Alps being road tested.

From launch, the Transit has never been officially sold in North America — despite the third generation being largely developed in Dearborn by Ford of Europe engineers. The model's only foray into the Americas so far has been in Mexico where the Transit debuted in 2007. Ford has stated that the eighth generation Transit platform will be global, also acting as a replacement for the long running E-Series range in the United States and Canada.

In October 2011, Ford confirmed the North American version, as the United Auto Workers revealed the retooling of the facility in Kansas City, Missouri for its assembly. Ford also registered trademark applications for Ford T-250, T-350, T-450, and T-550, which indicates that the Transit will likely follow the same naming scheme as the E-Series to differentiate itself from the smaller, mechanically unrelated Transit Connect that was introduced in North American in 2010.

Due to its four cylinder diesel engines, manual transmission, lower weight and more aerodynamic design, the Transit is considerably more fuel efficient, although less powerful than the E-Series, which is a mainstay with a V8 and automatic transmission. Currently the E-Series competes in North America with the Mercedes-Benz Sprinter—one of the Transit's main rivals in Europe.


A number of promotional Supervans were built, combining the outline and appearance of the Transit with the chassis and performance of a sports racing car.

A Mark 6 Ford Transit was used in a segment on BBC's Top Gear TV show. The show was broadcast on 10 July 2005. In the segment, Sabine Schmitz drove the Transit around theNurburgring to see if she could beat presenter Jeremy Clarkson's time in a Jaguar S-Type Diesel of 9 minutes 59 seconds. However, her best time was 10 minutes 8 seconds despite reducing the weight of the van.

A modified Mark 3 Transit was also used in Top Gear Australia's Ashes Special and Top Gear series 16 episode 2, where Richard Hammond (UK) raced the van against a Holden VE Utedriven by Shane Jacobson (Australia) in a drag race. Unknown to Hammond and the Australians, the van was actually a turbocharged Jaguar XJ220, and only had the shell of a Transit on


source: Wikipedia

Produced sub-models Models

FK 1000 / Taunus
1953 - 1965
1 I
1965 - 1978
2 II
1978 - 1986
3 III / VE6
1986 - 1991
4 IV / VE64
1991 - 1994
5 V / VE83
1994 - 2003
6 VI / V184 / V185
2000 - 2006
7 VII V347 / V348
2006 - 2012
2012 - ...
